1 Machine elements
13
Abb. 1: Machine elements
1
Control panel
2
Connection socket torch/electrode holder/compo-
nent guide
3
Torch switch socket
4
Gas connection torch
5
Connection socket component guide/electrodehold-
er
6
Transportation belt
7
Handle (hoisting point)
8
Mains cable holder
9
Main switch
10
Mains cable
2 Explanation of symbols
2.1 Meaning of the symbols in the opera-
tion manual
Danger to life and limb!
If the danger warnings are not observed,
slight or severe injury or even death may be
result.
Risk of material damage!
If the danger warnings are not observed,
damage to workpieces, tools and equipment
may result.
General information!
i i
Designates useful information about the
product and equipment
- 24 -
6
7
8
1
9
2
10
3
11
4
12
5
11
Shielding gas connection
12
Remote control socket
13
Accessories belt
The carrying strap is exclusively for
the transport by a person.
Illustrated or described accessories are
i i
partially not included in the scope of deili-
very. Subject to change.
2.2 Meaning of the symbols on the device
Danger!
Read the user information in the operation-
manual.
Unplug the mains plug!
Always pull out the plug before opening
the housing.Explanation of symbols
