Kick-back is the result of incorrect or deficient use.
It can be prevented by suitable precautionary meas-
ures, as described in the following:
■ Hold the saw firmly with both hands, with the
thumbs and fingers enclosing the chainsaw
handles. Bring your body and arms into a posi-
tion in which you can absorb the kickback forc-
es. If suitable measures are implemented, the
operator will be able to withstand the kick-back
forces. Never let go of the chainsaw (see fig. D).
■ Avoid an unusual body stance and never saw
above shoulder height. This will help to avoid
unintentional contact with the rail tip, and enable
improved control of the chainsaw in unexpected
situations.
■ Always use replacement guide rails and saw
chains prescribed by the manufacturer. Incor-
rect replacement guide bars and saw chains
may cause the saw chain to break and/or lead
to kick-back.
■ Adhere to the instructions of the manufactur-
er when sharpening and maintaining the saw
chain. If the depth limiter is too low, this in-
creases the tendency towards kick-back.
■ Do not saw with the tip of the guide bar. There
is a risk of kick-back.
■ Make sure that there are no nails or metal piec-
es in the cutting area. Pay special attention to
nails or pieces of iron around the cutting area.
Also be careful when sawing hardwoods where
the chain can get caught. This can cause kick-
back.
■ Start cutting at full power and always keep the
chainsaw at maximum speed while sawing.
■ Make sure that there are no objects on the floor
that you can trip over.
6.9 Residual risks
m DANGER
RISK OF INJURY !
Contact with the saw chain can lead to fatal cuts.
Never touch the saw chain with your hands while it
is running.
RISK OF KICK-BACK !
Kick-back can lead to fatal cuts.
DANGER OF BURNING !
The chain and guide bar heat up during operation.
32 | GB
7. Technical data
Weight unfuelled, without
cutting gear ..........................................approx.5,2 kg
Weight unfuelled,
with cutting gear ...................................approx.6.4 kg
Fuel tank ............................... approx. 550 cm
Tank for chain
lubricating oil ........................ approx. 260 cm
Usable cutting length* /
Guide rail .................................................. 45 cm (18")
Max. chain speed ..............................................22m/s
Chain pitch ......................................8.25 mm (0.325")
Driving link thickness ........................1.5 mm (0,059")
Type of saw chain ........................................................
KANGXING (pre-assembled): ................ .325.058-72
Type of guide bar
KANGXING (pre-assembled): ......... BE18-72-5810P
Chain wheel tooth pitch ...7 teeth / 8.255 mm (0.325")
Engine displacement ....................................... 45 cm
Max. engine power output per ISO 7293 ........ 1,8 kW
Idle speed n
Speed n
max
Spark plug ....................................................... L8RTC
* The actual cutting length may be less than the spec-
ified cutting length.
Noise
Sound pressure level L
Uncertainty K
Sound power level L
per ISO 22868 ............................................ 113.28 dB
Uncertainty K
Wear hearing protection.
Excessive noise can result in a loss of hearing.
The specified device emissions values have been
measured in accordance with a standardised test
procedure and can be used for the comparison of one
tool with another.
The specified noise emission values can also be
used for an initial estimation of the exposure.
Vibration
Vibration value at the rear
Handle per ISO 22867 .............................. 5.277 m/s
Vibration value at the front
Handle per ISO 22867 ...............................6.185 m/s
Uncertainty K .................................................1.5 m/s
m WARNING
Avoid the risks associated with vibration, e.g. the risk
of white finger syndrome (circulatory disorders) by
taking frequent breaks from work where you rub your
palms together, for example.
www.scheppach.com
.....................................3000 ± 300 rpm
0
................................................. 12000 rpm
per ISO 22868 ....... 98.9 dB
pA
................................................. 2.5 dB
pA
WA
................................................ 2.5 dB
WA
(0.55 l)
3
(0.26 l)
3
3
2
2
2
