10.2 electrical installation with circular plug-in connector
Danger!
risk of electric shock.
▶ Before working on equipment or device, switch off the power supply and secure to prevent reactivation.
▶ Observe applicable accident prevention and safety regulations for electrical equipment.
10.2.1 Designation of the contacts Type 8696
Circular plug
M12 x 1, 8-pole
Figure 24: Circular plug M12 x 1, 8-pole
10.2.2 connection of the positioner Type 8696
→
Connect the pins according to the model (options) of the positioner.
input signals of the control center (e.g. PLC) - circular plug M12 x 1, 8-pole
pin Wire color configuration
14)
Set-point value + (0/4 – 20 mA)
1 white
2 brown
Set-point value GND
grey Binary input +
5
6
pink Binary input -
Table 14: Pin assignment - input signals of the control center - circular plug M12 x 1, 8-pole
output signals to the control center (e.g. PLC) - circular plug M12 x 1, 8-pole
(required for analogue output option only)
pin Wire color configuration
13)
8 red Analogue position feedback +
7 blue Analogue position feedback GND
Table 15: Pin assignment - output signals of the control center - circular plug M12 x 1, 8-pole
The indicated colors refer to the connecting cable available as an accessory (919061)
14)
5
4
6
7
3
8
2
1
external circuit / signal level
1
2
5
6
external circuit / signal level
8
7
+ (0/4 – 20 mA)
GND
+ 0 – 5 V
10 – 30 V (log. 1)
GND
+ (0/4 – 20 mA)
GND
