7.4 function of the Dip switches
On
1 2 3 4
noTe!
Breakage of the pneumatic connection pieces due to rotational impact.
▶ When unscrewing and screwing in the transparent cap, do not hold the actuator of the process valve but the
connection housing.
Figure 14: Open positioner
→
To operate the DIP switches, unscrew the transparent cap.
noTe!
Damage or malfunction due to penetration of dirt and humidity.
▶ To observe degree of protection IP65 / IP67, screw the transparent cap in all the way.
→
Close the device (assembly tool: 674078
The assembly tool (674078) is available from your Bürkert sales office.
11)
28
Dip
).
11)
english
Transparent cap
Body casing
Connection housing
Actuator
Type 8696
Controlanddisplayelements
