10 elecTrical insTallaTiOn 24 V Dc
All electrical inputs and outputs of the device are not galvanically isolated from the supply voltage.
The kind of connection is used for the electrical bonding of the positioner:
• multipole
with circular plug-in connector M12 x 1, 8-pole
10.1 safety instructions
Danger!
risk of electric shock.
▶ Before working on equipment or device, switch off the power supply and secure to prevent reactivation.
▶ Observe applicable accident prevention and safety regulations for electrical equipment.
Warning!
risk of injury from improper installation.
▶ Installation may be carried out by authorized technicians only and with the appropriate tools.
risk of injury from unintentional activation of the system and an uncontrolled restart.
▶ Secure system from unintentional activation.
▶ Following installation, ensure a controlled restart.
