Type 8696
Technicaldata
6 Technical DaTa
6.1

conformity

In accordance with the EC Declaration of conformity, the positioner Type 8696 is compliant with the EC Directives.
6.2

standards

The applied standards, which verify conformity with the EC Directives, can be found on the EC-Type Examination
Certificate and / or the EC Declaration of Conformity.
6.3

licenses

The product is approved for use in zone 2 and 22 in accordance with ATEX directive 94/9/EC category 3GD.
Observe instructions on operation in an explosion-risk (Ex) area.
Observe the ATEX additional instructions.
The product is cULus approved. Instructions for use in the UL area see chapter "6.9 Electrical data".
6.4 Operating conditions
Warning!
solar radiation and temperature fluctuations may cause malfunctions or leaks.
▶ If the device is used outdoors, do not expose it unprotected to the weather conditions.
▶ Ensure that the permitted ambient temperature does not exceed the maximum value or drop below the mini-
mum value.
Ambient temperature:
Degree of protection:
Evaluated by the manufacturer:
IP65 / IP67 according to EN 60529
Only if cables, plugs and sockets have been connected correctly and in compliance with the exhaust air concept, see
5)
chapter "9 Pneumatic installation".
6.5 mechanical data
Dimensions
Body material
Sealing material
See type label
Evaluated by UL:
UL Type 4x Rating
5)
See data sheet
exterior: PPS, PC, VA,
interior: PA 6; ABS
EPDM / FKM
5)
