Atlas Copco MicroTorque G4 Produktanweisungen Seite 7

MicroTorque Controller G4
Pin
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
For information on configuration on the outputs and inputs, see ToolsTalk MT
- Reference - I/O status.
If used to reset the tool, the signal duration must be more than 20 ms.
All inputs are opto isolated.
Interface connection can be connected in PNP mode (source type, positive
logic), or in NPN mode (sink type, negative logic).
PNP and NPN mode can, if required, be mixed bank wise (e.g. OUT-A
PNP and OUT-B NPN).
If the DISABLE input is high, any start of the spindle will be inhibited. As
long as there is no error message shown on the controller display, the DIS-
ABLE status will be displayed as long as active.
I/O
DI00
DI01
DI02
DI03
DI04
DI05
DI06
DI07
DI08
DI09
DI10
DI11
IN A
IN B
B2 DGND
© Atlas Copco Industrial Technique AB - 9836 620200 00
EN
Description
Start
Reset
Unscrew
Program select bit 0
Program select bit 1
Program select bit 2
Program select bit 3
Program select bit 4
Disable
Program select bit 5
Not used
Not used
External common line for
DI00-DI07
External common line for
DI08-DI11
Internal ground
Product Instructions
Screw cylce sequence en-
abled
Sequence Start
Error confirmation
Unscrew
Product type select bit 0
Product type select bit 1
Product type select bit 2
Not used
Sequence reset
Not used
Joint start
Not used
Not used
External common line for
DI00-DI07
External common line for
DI08-DI11
Internal ground
7
