Operation
6. Operation
6.1 ILR102x
Once the sensor has been connected to the power supply the green "POWER" LED lights up.
6.1.1

Control and Display Elements

LED Q
B
yellow
LED Fast/Slow
orange
LED Power
green
LED
Q lights
A
Q lights
B
Fast/Slow flashes slow
flashes fast
Power lights
Menu lights
LED Menü
red
LED Q
A
yellow
SET key
Specification
Switching output Q active
A
Switching output Q active
B
Sensor response time: Slow
Sensor response time: Fast
Power supply OK
Menu navigation
Operation is done with the keys Set and
Toggle.
Set: Setting or resetting the selected func-
tion. The value is stored if the menu LED
flashes 3 times.
Toggle: Switches through the menu func-
tions.
IMPORTANT!
The sensor needs a
warmup time of about
15 min for repeatable
measurements.
Toggle key
