Operation ILR11xx
Command Name
execute conti-
„ECM" nuous measu-
rement
„GDB" get energy
get serial
„GNR"
number
„GSI" get error status
„GTE" get temperature
„GVE" get version
help command/
„GCM"
get commands
input conti-
„ICM"
nuous mode
„IDO" input offset
Data to ILR11xx Data from ILR11xx
-
-
Energy value -0..-120dB
-
„xxxxxxxxxx"
- „DDDDDDD"
76543212
- „±DDD"
„Fx9x $Revision X.XX$"
-
all available commands
„0" , 1"
-12000--+12000
bzw.
-48000.. +48000
Specification
Continuous measurement output ist set and triggered
ACK
by the next request for measured values
Indicates the amount of receiving energy
Serial no. is sent as ASCII text
(max. 24 characters)
Output of the error state,
D="0": no error D="1": error
D7: Transmitter faulty
D6: Receiver blinded or faulty
D5: Temperature warning: T <-10 °C or +70 °C
D4: Target out of range or receiver faulty
D3: Temperature error: T > +85 °C
D2: Supply voltage to low
D1: PLL unlocked
D0: always „0"
DDD = Internal temperature in °C
Software version is sent
All available commands are sent in text format
Measurement mode setting:
ACK „0" = continuous measurement output,
„1" = single measurement output
Offset setting in [mm]
ACK
or [INCH * 100]
