Installation
5.4

Electrical Connection

The sensors contain 5-pin connectors (ILR102x) or 12-pin con-
nectors (ILR11xx). Bending radius of the supply and output cable
(available as an optional accessory):
PC1x 34 mm (once), 84 mm (permanent)
PC11x 47 mm (once), 116 mm (permanent)
5.4.1 ILR102x
Fig 5.10: Female cable connector, view on solder pin side
1
+U
5
I
OUT
4
Switching output Q
2
Switching output Q
ILR102x
3
GND supply/output
Fig. 5.11: Pin assignment
(18 ... 30 VDC)
B
(4 ... 20 mA)
A
B
+U
Switching output
0 V (GND)
Fig. 5.9: Wiring diagram switching
outputs
Color
Pin
PC1x
1 brown
mA
2 white Switching output QB, I
3 blue
4 black Switching output QA, I
5 grey
B
R
Last
U <2.4 V
max
Specification
Ub + 18 ... 30 V
100 mA
max.
0 V (GND)
100 mA
max.
Analog output 4 .. 20 mA
