Installation and Assembly

4.
4.1
Free return of measur-
ing wire not permitted!
Do not pull out the measuring wire beyond the measuring range listed.
> Risk of injury due to
> Damage to or destruction of the sensor
whiplash of the wire
with eyelet.
Do not damage the measuring wire.
> Destruction of the
Do not oil or grease the measuring wire.
wire and/or the
Do not kink the measuring wire.
sensor.
Do not pull the measuring wire diagonally.
Secure the measuring
Do not let the measuring wire drag around objects.
wire during installation
work.
Attach the measuring wire to the measured object while the wire is retracted.
Do not wrap the measuring wire around body parts.
4.2
The slot nuts can be mounted on each sensor side and positioned as desired.
The sensor does not have to be oriented in a special way.
i
i
wireSENSOR, WDS P85 Mechanics
Installation and Assembly

Precautions

Sensor Mounting

Use four M6 screws and two slot nuts to mount the
Select the installation position in such a way that damage to or contamination of the measuring wire is
avoided.
If possible, prefer an installation position in which the measuring wire exits downward. This prevents
liquids from entering the measuring wire outlet.
Do not let the measuring wire snap! There is no liability for material defects in case of damage due to
snapping.
sensors, see Fig. 2.
