Installation
5.2
The series ILR1021/1101/1151 sensors measure
the distance to a reflector. Direct measuring to a
target is not possible. Depending on the measu-
ring range different types of reflectors are used.
IMPORTANT!
Measuring
against a reflector
only with series
ILR1021/1101/1151
sensors.
Fig. 5.2: Distances of the different reflectors to
the sensor
Page 56
Reflector Mounting
ILR-R700
ILR-R540
ILR-R660
ILR-R460
ILR-R250
ILR-RF250
B
b
t
d
A
B
a
(mm)
ILR-RF250 250 250
---
ILR-R250
248 248 218
ILR-R 460
460 460 430
ILR-R660
660 660 630
ILR-R540
540 540 510
ILR-R700
700 700 670
Fig. 5.3: Reflector drawings, dimensions
in mm, not to scale
a
A
b
d
t
---
---
0.5
218
6.5
4.5
430
6,5
4.5
630
6.5
4.5
510
6.5
6.8
670
6,5
6,8
