Appendix
ILR-APB Plug adapter ProfiBus
ILR-ADN Plug adapter DeviceNet
ILR-Pconfig
10.2
Measured value:
Binary output:
Binary input:
Analog output:
Analog input:
Error state:
Error bits:
Driver files for bus
Bit 15 to Bit 8:
adapter are enclosed
Bit 7:
on the disk which is
Bit 6:
supplied with the re-
Bit 5:
spective bus adapter.
The disk contains the Bit 4:
following driver files:
Bit 3:
Bit 2:
.gsd
Bit 1:
Driver for ProfiBus
Bit 0:
.eds
Driver for DeviceNet
Parameters:
Page 86
PC software
ProfiBus, DeviceNet Plug Adapter
none
none
none
2 * 16bit -> measured value in millimetres (word 0: measured value bit 0 to 15,
word 1: measured value bit 16 to 32)
Error output consisting of 16 bits
always "0"
No start, transmitter faulty
Receiver blinded or faulty
Temperature warning: T < -10 °C or T > +70 °C
No stop signal, target out of range or receiver faulty
Temperature error: T > +85 °C
Supply voltage too low
PLL unlocked
always "0"
none
