Operation ILR11xx
Com-
Name
mand
get all parame-
„GAP"
ters
Page 76
Data to
Data from ILR11xx
ILR11xx
all parameters in text format:
„Fx9xILA $Revision X.XX$"
„target is on/off/xx seconds on" AA :
Uart mode
„Q1: AA Mode=BB
Limit1=CC Limit2=DD
Hyst=EE INV=ON/OFF"
-
„Q2: AA Mode=BB
Limit1=CC Limit2=DD
Hyst=EE INV=ON/OFF"
(ILR11x0 only: „Quana:
VALUE=FF LIMIT1=CC
LIMIT2=DD INV=ON/OFF)
„output = GG"
„offset = YYYY"
„password dis/enabled"
„Error-Status = DDDDDDDD"
Specification
all parameters of the ILR11xx are read:
X.XX:
Revision number
YYYY: User offset [mm] or [10 MIL]
"ON" = Output HIGH,"OFF" = Output LOW
Mode: "0" = Output off,
BB:
„1" = 1 switching point, „2" = 2 switching points
CC:
switching point 1, Offset..12000+Offset
DD:
switching point 2, Offset..12000+Offset
EE:
Hysteresis, 0..254 [mm]
GG:
Unit, „10MIL" or „MM"
DDD:
Error state:
FF:
Analog value, 0..4095
Output of the error state: D="0": no error,
D="1": error
D7: Transmitter faulty
D6: Receiver blinded or faulty
D5: Temperature error: T < -10 °C or T > +70 °C
D4: Target out of range or receiver faulty
D3: Temperature error: T > +80 °C
D2: Supply voltage to low
D1: PLL unlocked
D0: always „0"
