Operation ILR11xx
Com-
Name
mand
input hysteresis
„IH1"
Q1
input hysteresis
„IH2"
Q2
input limit
„IL1"
Q1 - 1
input limit
„IL2"
Q2 - 1
input limit
„IL3"
Q analog 1
input limit
„IL4"
Q1 - 2
input limit
„IL5"
Q2 - 2
input limit
„IL6"
Q analog 2
„IM1" input mode Q1
„IM2" input mode Q2
„INA" input norm
Q analog
Page 78
Data to ILR11xx Data from ILR11xx Specification
„000".. „254" or
„000".."999" (INCH)
„000".. „254" or
„000".."999" (INCH)
Offset ...
+12000+Offset or
Offset .. 48000+Offset
Offset ...
+12000+Offset or
Offset .. 48000+Offset
Offset ...
+12000+Offset
Offset ...
+12000+Offset or
Offset .. 48000+Offset
Offset ...
+12000+Offset or
Offset .. 48000+Offset
Offset ...
+12000+Offset
„0" , „1" , „2"
„0" , „1" , „2"
„0" , „1"
Hysteresis setting around the switching point Q1 in [mm]
ACK
or [INCH * 100]
Hysteresis setting around the switching point Q2 in [mm]
ACK
or [INCH * 100]
Setting of the first switch point of Q1 in [mm]or
ACK
[INCH * 100]
Setting of the first switch point of Q2 in [mm]or
ACK
[INCH * 100]
ILR11x0 only: Setting of the 0% point of the analog charac-
ACK
teristic, seeCap. 6.2.5
Setting of the second switch point of Q1 in [mm]or
ACK
[INCH * 100]
Setting of the second switch point of Q2 in [mm]or
ACK
[INCH * 100]
ILR11x0 only: Setting of the 100% point of the analog cha-
ACK
racteristic, seeCap. 6.2.5
ACK „0" = not active, „1" = 1 switching point, „2" = 2 swit-
ching points
ACK „0" = not active, „1" = 1 switching point, „2" = 2 switching
poinst
ACK ILR11x0 only: „0" = Q, „1" = Q inverted
