Accessories - MICRO-EPSILON optoNCDT ILR 102 Serie Betriebsanleitung

Appendix
10.
10.1
mm
(inches)
Page 84
Appendix

Accessories

28
(1.10)
R 2.6
(.10)
20 °
ø 3.1
(.12)
R 2.6
(.10)
4
(.16)
11
(.43)
25
(.98)
50
(1.97)
14
(.55)
ø 3.1 (.12)
45
(1.77)
Fig. 10.1: Dimensions ILR-MA90,
mounting bracket for sensor
