Operation ILR11xx
6.2.6 Offset
An offset value can be entered or teached-in in the range ±100,000 mm (or corresponding inch value). The
measured value is then increased or decreased by the programmed offset value depending on the preceding
sign. This can compensate a mounting position which does not correspond with the zero point of the plant.
If an offset value is teached-in it is stored with a negative sign, i.e. the teach-in position corresponds with the
zero point. The preceding sign can also be set manually.
The offset value can be set back to "0" with the CLEAR function.
Example: Actual distance:
Offset value:
Output value:
6.2.7 Unit
Unit makes it possible to choose between millimetres and inches as the display and output unit. The inch
display and output via the interface is value * 100 Inch, i.e. a displayed value of "18835" is equivalent to 188.35
Inch. Factory setting is mm.
6.2.8 Interface and Parameter
the series ILR11xx sensors contain RS422 / SSI1/10, SSI1/8 - compatible or EXTernal BUSadapter interfaces.
implementiert. Select the interface in the Serial menu. When EXT BUS is selected, "SEARCH BUS ..." appears
in the display until the connection is established. Bus adapters are available as an optional accessory. Once
the connection has been successfully established the above mentioned text disappears. If the connection
cannot be established the text remains in the display and the process must be cancelled with the ESCape key.
The process can be restarted once the electrical connection has been restored.
3000 mm
- 1200 mm
1800 mm
Factory setting:
Offset = 0
DIST mm
4784
DIST inch
18835
