Operation ILR11xx
6.2.5 Switching Behavior, Hysteresis and Analog Output
You can adapt the switching behavior to the local condition when reaching the switching point. The settings for
Q1 and Q2 can be done independently of each other. See the listed switching states below (Mode Qn menu):
Qn single switching
Qn single switching (factory setting)
Qn double switching
Qn double switching
Teach-in or manual input of switching points is possible (Teach n.1, n.2 menu). Teach n.2 is used for a double
switching output.
The hysteresis of the switching outputs prevents frequent or unmeant switching of the output if the target mo-
ves slightly around the switching point.
Range of the hysteresis: ILR115x = 5 mm, ILR110x = 10 .. 254 mm
Step size: ±1 mm
The hysteresis is located symmetrically around the switching point. If the upper limit is reached the limit value
of measuring range is valid as upper limit.
Analog output (ILR11x0 only)
Range: 4 ... 20 mA
Characteristic curve (mode ANA menu):
Mode 1 = rising characteristic (factory setting),
Mode 2 = falling characteristic
Operation mode
Teach-In
<Setup>
Teach-In
<Set Qn>
Mode Qn
Teach n.1
Teach n.2
HYST n
Factory setting for
teach-in values:
End of measuring
range
