1 INTRODUCTION
The KRPX+ planetary gearbox will give you complete satisfaction if all of the following mounting,
operating & maintenance instructions are respected.
1.1 Warnings
WARNING! HANDLING OPERATIONS.
The KRPX+ unit can be handled by the main housing or, with lifting rings, by the pinion
tapped hole.
WARNING! LUBRICATION REQUIREMENTS.
The rack and the output gears must be lubricated before running the KRPX+. The KRPX+
is delivered WITHOUT OIL: refer to lubrication chapter in this manual to respect all
lubrication requirements.
Any damage due to incorrect lubrication will void the warranty.
1.2 Gearbox identification
Each unit can be identified through its identification plate and the serial number indicated on it. The serial
number must be given for any correspondence on a particular unit.
Serial number
Drawing code
Designation
1.3

Long term storage

Each gearbox is delivered wrapped and greased for 1 month anti-corrosion protection. Gearboxes which
are not installed shortly after receipt should be stored in a dry atmosphere with temperature between 0°C
& 40°C. The unit must be filled completely with oil for storage.
This document must not be reproduced nor information therein disclosed without our authorization
KRPX+ User manual
861607
RX128460-12
KRPX4+R.31.3.H
Ref.: RX182/010
Version 01/2017 - English
Shipment date
NOV. 2016
Reduction ratio
31
Backlash (if
needed)
