Technical Data - REDEX KRPX1+ Betriebs-, Montage- Und Wartungsanleitung

2

TECHNICAL DATA

2.1 Gearbox
Maximum
acceleration
output
torque (Nm)
Max. input
Speed (rpm)
Approx.
Weight (kg)
2.2 Output pinion
Theoretical pitch
diameter (mm)
Note:
Data are subjected to change without prior notices.
2.3 Mounting position nomenclature
Output flange position / motor flange position (if different) with:
- B5 horizontal
- V1 vertical down
- V3 vertical up
Examples:
V1/B5: output flange vertical down / motor flange horizontal
B5: output flange & motor flange horizontal
This document must not be reproduced nor information therein disclosed without our authorization
KRPX+ User manual
i=5
1 st. i=7
i=10
i=17
i=21
i=31
2 st.
i=46
i=61
i=91
1 st. i=5, 7, 10
2 st. i=21 to 91
KRPX+R
1 st.
2 st.
KRPX+M
1 st.
2 st.
Module
Helical: 19°31'42''
Straight
KRPX1+ KRPX2+
648 1750
665 1750
473 1400
683 1838
534 1400
753 2100
473 1400
656 2013
473 1400
5000 5000
6000 6000
30 68
32 71
28 61
30 64
KRPX1+ KRPX2+
3 4
57.30 76.39
57 76
Ref.: RX182/010
Version 01/2017 - English
KRPX3+ KRPX4+
- -
- -
3238 6125
2625 6125
3850 6300
2468 4480
2695 4970
2695 4970
4000 -
6000 5000
- -
143 233
- -
130 202
KRPX3+ KRPX4+
5 6
95.49 114.59
95 114
KRPX5+
-
-
-
7520
10050
8800
8800
8800
-
4000
-
350
-
310
KRPX5+
8
127.32
128
