418/685
Funktionen und Parameter
Funkti-
onscode
H3.24 MEP: Active Device Address (Topology)
H3.25 MEP: IP address is remnant (PROFINET)
MEP: EtherCAT List of Input Process Data
H3.26
(Master)
MEP: EtherCAT List of Output Process Data
H3.27
(Master)
H3.28 MEP: Input Process Data Length (Master)
H3.29 MEP: Output Process Data Length (Master)
H3.30 MEP: List of Input Process Data
H3.31 MEP: List of Output Process Data
H3.32 MEP: Input Process Data Length (Slave)
H3.33 MEP: Output Process Data Length (Slave)
H3.34 MEP: Communication Platform State
H3.35 MEP: Communication Diagnosis Flags
H3.36 MEP: ComCycle Periods [ns]
H3.37 MEP: Communication Phase
H3.40 MEP: Industrial Ethernet Protocol Request
H3.41 MEP: Industrial Ethernet Protocol Active
H3.42 MEP: Industrial Ethernet Protocol Logicware
H3.49 MEP: EtherCAT State
H3.51 MEP: Modbus/TCP Alternative TCP port
H3.63 MEP: List of external parameters
H3.71 MEP: Subsystem identification parameter
H3.96 MEP: FWA string
Tab. 12-121: Parameterliste
H3.06 MEP: IP Options
●
Bit 0: DHCP aktiviert (MEP empfängt die IP-Adresse H3.03 von einem DHCP-
Server), andere Bits unbenutzt.
H3.18 MEP: Visual Status Indicators
●
Dieser Parameter liefert eine Datendarstellung der LED-Anzeigen.
Bit
31 bis
-
18
17
Link P2
16
Link P1
Bosch Rexroth AG R911369847_Ausgabe 09
Parametername
Name
Frequenzumrichter Baureihe EFC x610
Datentyp
Werkseinstellung
WORD
0
DWORD
0
WORD LIST
0x0000, 0x0000
WORD LIST
0x0000, 0x0000
USHORT
0
USHORT
0
WORD LIST
0x6001, 0x1002
WORD LIST
0x6000, 0x600A
USHORT
4
USHORT
4
DWORD
-
DWORD
-
ULONG
0,0,0
USHORT
0
CHAR LIST
S3
CHAR LIST
S3
CHAR LIST
S3L
USHORT
1
USHORT
0
WORD
-
CHAR LIST
<MANU>
CHAR LIST
<MANU>
Funktion
Reserviert
1 = Ethernet-Link vorhanden
0 = Kein Ethernet-Link
Attri.
Read
Run
Read
Read
Read
Read
Stopp
Stopp
Read
Read
Read
Read
Read
Read
Run
Read
Read
Read
Run
Read
Read
Read
