11.12

Travelling speed und drive speed

The travelling speed and drive speed while swathing depend on:
• forage quantity
• ground
• degree of dryness
Use these as rough guidelines:
• PTO speed approx. 450 rpm
• Travelling speed approx. 8 - 10 km/h
Drive speed and travel speed must be adapted to each individual operation.
Pos: 31.95 /BA/Bedienung /Schwader/Hinweis: Fahrgeschwindigkeit @ 77\mod_1310104464864_78.docx @ 667725 @ @ 1
Note
The travelling speed is based on the work image (orderly rake work with good formation of
swaths).
Pos: 31.96 /BA/Bedienung /Schwader/Schwaden/Schwaden @ 303\mod_1414136844348_78.docx @ 2357220 @ 2 @ 1
11.13

Swathing

• Ensure there is no one in the working range of the machine.
• Raise lower links by approx. 100 mm (the height from lower link pinions to ground is approx.
630 mm).
• Raise outrigger arms into headland position.
• Switch on universal shaft at low engine speed.
• Increase speed slowly to approx. 450 rpm.
• Lower outrigger arms into working position.
• Move single-action control unit to position ("Lower / float position") to ensure the soil
adaption of the chassis when using the machine for work.
• Select travelling speed so that the crop is picked up cleanly and completely.
• Readjust working height, if necessary.
