Start-up
Pos: 27.9 /Überschriften/Überschriften 2/K-O/Maschine an den Traktor ankuppeln @ 279\mod_1405350506791_78.docx @ 2150095 @ 2 @ 1
9.2

Connect the machine to the tractor

Pos: 27.10 /BA/Erstinbetriebnahme/Wender/Hinweis - Je nach Traktortyp evtl. Anhängekupplung abbauen. @ 172\mod_1370506026261_78.docx @ 1479993 @ @ 1
CAUTION! – Collision with the trailer coupling
Effect: Damage to the tractor or machine
Depending on the type of tractor, the top link of the tractor and/or the universal shaft of the
machine could collide with the trailer coupling.
• To prevent damage, it may be necessary to detach the trailer coupling. For further
information refer to the tractor manufacturer's operating instructions.
Pos: 27.11 /BA/Inbetriebnahme/Schwader/Hinweis Maschine befindet sich in Transportstellung @ 291\mod_1410425539165_78.docx @ 2294265 @ @ 1
Note
In the following description, one assumes that the machine (after final assembly) is in the
transport position.
Pos: 27.12 /BA/Inbetriebnahme/Schwader/Anbau an den Traktor/Unterlenker ankuppeln_Bild_SW 700# @ 173\mod_1371109817897_78.docx @ 1485999 @ @ 1
Fig. 15
Pos: 27.13 /BA/Inbetriebnahme/Schwader/Anbau an den Traktor/Unterlenker ankuppeln_Text @ 133\mod_1349872612749_78.docx @ 1178384 @ @ 1
• Connect the machine according to the operating instructions of the tractor manufacturer to
the lower links, raise it slightly and secure it.
• Place the machine onto the parking support.
• Turn off the tractor and secure it.
Pos: 27.14 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
46
SW700060
