1) Hoop guard
2) Outrigger arm
3) Warning panel
4) Frame rear
5) Wheel chock
6) Tine arm
7) Drive universal shaft
* only for Plus version
Pos: 20.4 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
8) Universal shaft bracket
9) Parking support
10) Frame front
11) Support tine guards
12) Electronic rotor height
adjustment*
13) Transverse link
14) Rotor
Machine Description
15) Rotor chassis
16) Rotor gearbox
17) Universal shaft rotary drive
18) Overload protection
19) Main gearbox
20) Lighting
21) Chassis
