Malfunction
Rotor does not work smoothly.
High forage contamination.
Swath width too large
In headland position, one rotor
goes down and the other one
goes up.
It is not possible for the rotor to
adapt to unevenness of the
ground.
The electrical adjustment of the
working height does not work
properly.
Pos: 44 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
Possible cause
Working height is set too high.
Working speed is too high.
Speed is too low.
Side rotor inclination adjusted
incorrectly.
Tine arm(s) crooked.
Working height is set too low.
Tine arm(s) bent.
Working width too long.
Speed is too low.
Rotors are not swivelled up into
headland position.
The lower links of the tractor are
set too high or too low.
The tractor hydraulics is not in the
float position.
Fuse defective.
Malfunctions - Causes and Remedies
Remedy
Lower working height.
Reduce driving speed. Guide value
8 - 10 km/h. Slow down in case of
uneven terrain or high amount of
forage.
Increase the speed. Guide value
450 rpm
Change the side inclination (refer to
chapter Operation "Setting the Side
Inclination").
Replace tine arms.
Raise working height.
Replace tine arms.
Change working width.
(Swadro TC 760)
Increase speed.
Actuate hydraulics until the rotor
arms rest against the stops.
Align frame horizontally (the height
from lower link pinions to ground is
approx. 63 cm).
Set tractor hydraulics to float
position.
Replace the fuse in the switch box
which is mounted on the frame.
