Special equipment
Pos: 39.6 /BA/Sonderausstatung/Schwader/Kette zur Tiefenbegrenzung der Unterlenker @ 2\mod_1202808127295_78.docx @ 61611 @ 2 @ 1
17.2

Chain for height restriction of suspension arms

4
Figure 58
• Secure chains (1) with a spring-type slotted straight pin (3) and a washer (2) at the
suspension arm seats.
• Attach chain hooks (4) to the tractor.
• Select chain length according to desired max. lowering level.
Note
Spare tine loss safeguards Order No. : 153 479 0
Chain for height restriction of suspension arms Order No.: 250 759 0
Pos: 40 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
100
1
2
3
