Operation
Pos: 31.83 /Überschriften/Überschriften 2/U-Z/Zinkenschutze anbringen @ 36\mod_1263218287043_78.docx @ 338452 @ 2 @ 1
11.10

Protecting the tine tips (transport position and rotary rake switched off)

Pos: 31.84 /BA/Bedienung /Schwader/Zinken / Zinkenarme/Zinkenschutze anbringen Bild SW TC 680_760 @ 213\mod_1389944201475_78.docx @ 1747510 @ @ 1
Fig. 42
Pos: 31.85 /BA/Bedienung /Schwader/Zinken / Zinkenarme/Zinken unter 2 m mit Zinkenschutze sichern Text @ 36\mod_1263218917700_78.docx @ 338477 @ @ 1
The tines must be fitted with guards which are positioned at less than 2 m in transport position
or when the machine is switched off. The tine guards are located on the front supports (right
and left side of the machine).
• Connect the tine guards (1) onto the tines.
Pos: 31.86 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
74
1
1
SW700075_1
