Operation
Pos: 31.15 /Überschriften/Überschriften 3/A-E/B/Bei Ausführung mit hydraulischer Einkreiselaushebung @ 77\mod_1310050459478_78.docx @ 667495 @ 3 @ 1
11.2.2
For design with hydraulic single-rotor lifting mechanism
Pos: 31.16 /BA/Bedienung /Schwader/Kreiselarme senken/heben/Kreiselarme senken hydraulische Einkreiselaushebung SW TC 680_760 @ 214\mod_1390381679853_78.docx @ 1755064 @ @ 1
Fig. 28
•
Insert the hydraulic control unit (4) into the bracket in the tractor cabin.
•
Switch the switching valve (3) to the central position (II).
•
Switch on the tractor.
•
To relieve the locks (1), actuate the single-action control unit at the tractor and pressurise
the hydraulic cylinders.
•
To release the locks
•
Set the single-action control unit (red 1+) of the tractor to the float position.
•
When the rotors are in the working position, release the actuating rope (2).
•
Switch off the tractor and secure it against the possibility of rolling back.
Pos: 31.17 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
60
(1), pull the actuating rope
2
(2) and keep it tensioned.
1
SW700066_1
