13.4

Tightening Torques (Countersunk Screws)

Pos: 37.15 /BA/Wartung/Drehmomente / AnziehdrehmomenteDrehmomente über Innensechskant (2014-11-14 13:04:06) @ 45\mod_1277106232328_78.docx @ 411205 @ @ 1
The tightening torque M
(unless otherwise indicated).
A
Ø
M 4
M 5
M 6
M 8
M 10
M 12
M 14
M 16
M 20
NOTE
The table above applies only to countersunk screws with hexagonal socket heads and metric
threading that are tightened by the hexagonal socket head.
Pos: 37.16 /Layout Module /---------------Seitenumbruch---------------- @ 0\mod_1196175311226_0.docx @ 4165 @ @ 1
is stated in Nm
A
5.6 8.8 10.9 12.9
M (Nm)
A
2.5 3.5 4.1
4.7 7 8
8 12 15
20 29 35
23 39 58 67
34 68 100 116
108 160 188
168 248 292
340 488 568
A = Thread size
(The stability class can be seen on the head of the
screw.)
A
Maintenance
BM 400 0234
87
