KEB COMBICONTROL C6 Gebrauchsanleitung Seite 163

ANAlOGE KEB I/O-MODUlE
6500, 14 Input 5 low
6500, 15 Input 6 low
6500, 16 Input 7 low
6500, 17 Input 0 high
6500, 18 Input 1 high
6500, 19 Input 2 high
6500, 20 Input 3 high
6500, 21 Input 4 high
6500, 22 Input 5 high
6500, 23 Input 6 high
6500, 24 Input 7 high
6500,
-
25...32
6500, 1 ResetErrorAck
6500, 3 EtherCAT Error
6500, 4 ConfigError
7001 Module Control
7001, 0 Number of Entries
7001, 1 Reset Error
RO=Read only, RW= Read/Write, P=Prozessabbild
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
Array
UINT8 1
BOOL
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO
RW P
163
