ANAlOGE KEB I/O-MODUlE
6401, 2 Analog Input 1
6401, 3 Analog Input 2
6401, 4 Analog Input 3
6401, 5 Analog Input 4
6401, 6 Analog Input 5
6401, 7 Analog Input 6
6401, 8 Analog Input 7
6500 StateWord
6500, 0 Number of Entries
6500, 1 ResetErrorAck
6500, 3 EtherCAT Error
6500, 4 ConfigError
7001 Module Control
7001, 0 Number of Entries
7001, 1 Reset Error
RO=Read only, RW= Read/Write, P=Prozessabbild
134
UINT16
UINT16
UINT16
UINT16
UINT16
UINT16
UINT16
Array
UINT8 16
BOOL
BOOL
BOOL
Array
UINT8 1
BOOL
RO P
RO P
RO P
RO P
RO P
RO P
RO P
RO
RO P
RO P
RO P
RO
RW P
