13.

Technical Data

Model:
Wing span ........................................ 2540 mm
Length.............................................. 1670 mm
Weight ............................................ depending on equipment from approx. 5650 g
Wing area ........................................ 90.2 dm²
Control ............................................. at least 6 channels
Drive recommendation of the combustion motor:
Displacement for 2-stroke engine ... 20 to 30 ccm
Displacement for 4-stroke engine ... 30 to 50 ccm
Drive recommendation of the electric motor:
Power consumption ......................... as of approx. 1500 W
Drive battery .................................... as of 6-cell LiPo, min. 4500 mAh, discharge rate 30C
Suitable Servos:
Installation dimensions .................... approx. 40.5 x 20 x 38.5 mm
Controlling torque ............................ Aileron servo: > 65 Ncm
Elevator and rudder servo: > 65 Ncm
Throttle servo: > 40 Ncm
