5.

Scope of Delivery

Before you start assembly, check the parts for the scope of delivery of your model.
Main components:
• Fuselage
• Left and right wings
• Plug-in pipe for wings and wing supports
• Elevator rudder
• Fin
• Cowling
• Main landing gear, tail spur, wheels
• Small parts such as screws and linkage parts (*)
• Decal sheet
• Operating instructions
(*) The universal small parts set enclosed with this construction kit contains all parts needed to set up the model.
However, it is possible that not all present parts from this set are needed for construction or fit your ideas. They
can be replaced by parts from your own workshop.
The following components not included in delivery are required for assembly and operation:
Assembly:
Soldering gun, cutter knife, screwdriver, 30-minute epoxy resin, possibly thixotropic agents (micro-balloon or cotton
flock) for thickening the resin, threadlocker varnish, super glue and sand paper.
Attention!
Observe the safety information of the respective manufacturer when using glues and work with glues in
well-ventilated rooms only.
Operation:
• Flying requires a suitable (computer) remote control system with at least 6 channels and a large receiver battery (as
of 2500 mAh).
• If the model is equipped with a combustion engine, you will need 6 servos (2x ailerons, 2x elevators and 1x rudder of
the standard class with a least 65 Ncm thrust; as well as a throttle servo of the standard class with at least 40 Ncm
thrust).
You will also need a 2-cycle combustion engine with a displacement of 20 - 30 ccm (or a 4-cycle combustion engine
with a displacement of 30 - 50 ccm), the associated muffler and a propeller that belongs to the muffler.
A fuel tank is enclosed in the delivery. For this, you need additional suitable hoses, filters and fittings, however, which
must be purchased separately.
29
