Patient Comfort
The FLEXISENSOR SD line is designed to slip into a disposable bandage of twa styles
(butterfly and coban) which conform comfortably and safely to the particular patient's
anatomy.
A.
Sensor Selection and Application
Selection of a specific sensor is based on the patient's age, sex, physical condition,
and expected monitoring duration.
General guidelines for the selection of a sensor are provided in the Sensor Selection
Chart, which follows.
instructions for the application of a sensor to a patient are provided in each sensor
package.
B. Sensor Connection to the ACCUTORR
3SAT/4SAT
1. Align the cable connector on the sensor assembly with the SaO2 Patient Connector
(13) on the ACCUTORR 3SAT/4SAT.
2. Push the cable connector into the SaO2 Patient Connector (13). Confirm that the
cable connector is securely in place.
TO OBTAIN MAXIMUM CABLE USE, DO NOT TWIST THE CABLE CONNECTOR
WHEN
ATTACHING ΤΟ OR DISCONNECTING FROM THE ACCUTORR 3SAT/4SAT.
C. Sensor Inspection
Before use, always inspect sensors, cables, and connectors for damage, ie., cuts and
abrasions.
Do not use the sensor, cable or connector if damaged.
Replace with a
good working sensor.
For long sensor life:
-Do not drop on the floor, or give other sharp shocks to the sensor(s).
Between use, store the sensors in the optional FLEXISENSOR SD Organizer,
accessory pouch, or coil the sensor cable and store on the side of the ACCUTORR
using the optional cable retainer.
For accessory part number information see Section 5.2, "Optional Accessories".
-Avoid running any cart, bed, or any piece of equipment over the sensor cable.
-Avoid strong pulls on the sensor cable (10 ibs/4kg).
-Watch for cracks in the DIGISENSOR housing.
1-22
