if the self-test is not successful, one of the following messages will be displayed on the
LCD:
RAM TEST FAILED
RS232 PORT FAILURE
ROM TEST FAILED
D.S. BUS FAILURE
if any of these messages are displayed, the monitor will not operate.
See Section
1.3.4.8, LCD Messages, for further instructions.
1.3.3
Initial Control Settings
The following initial settings are automatically selected at power on.
INITIAL SETTING
DEFAULT
FUNCTION
ON POWER UP
SETTINGS
Timer Interval
As last set
OFF
Hold
OFF
OFF
Patient Size
As last set
Adult
Trend Display
Tabular List
Tabular List
Systolic Alarm Limits
As last set
OFF
Diastolic Alarm Limits
As last set
OFF
Mean Alarm Limits
As last set
OFF
Rate Alarm Limits
As last set
OFF
Alarm Volume
As last set
MED
SaO2 Beep Volume
As last set
LO
Record
OFF
OFF
Initial Cuff inflation
View Angle
Adult/Child: 180mmHg
Neonate:
120mmHg
As last set
1.3.3.1
View Angle (Contrast)
The view angle is changed by pressing the H] (26) and LO (28) keys at any time
Adult/Child:
180mmHg
Neonate:
120mmHg
12 o'clock view nominal
during normal operation (except when in the Alarm Set Mode).
A beep is heard each
-
time one of these keys is pressed.
A double beep is heard when the last setting has
been reached for that key.
NOTE:
The Hi and LO keys have a dual function. When in the Alarm Set Mode the
keys are used to set the alarm limits. Therefore, pressing these keys in the Alarm Set
Mode will not alter the view angle.
Revised
08/24/90
1-15
