Behaviour in an emergency
Initiate the necessary first aid measures for the injury
and seek medical assistance as quickly as possible.
Protect the injured person from further harm and
keep them calm. A first-aid kit according to DIN 13164
should always be available at the workplace in the
event of an accident.
Any material taken from the first aid kit must be re-
filled immediately. When you request assistance, pro-
vide the following information
1. Place of the accident
2. Nature of the accident
3. Number of injured
4. Nature of the injuries
6. Technical data
Technical data
Number of blades
Planing shaft speed
Dimensions
Weight
Technical data - Jointer
Max. planing width
Max. chip take-off
Truing stop l x h
Truing stop pivot range
Planing table size
Technical data - Thicknesser
Max. planing width
Max. workpiece
thickness for
thicknesser
Max. chip take-off
Thicknesser table size
Drive
Motor
Rated input P1
Subject to technical changes!
Noise
The noise levels have been determined in accord-
ance with EN 61029.
Sound pressure level L pA
Uncertainty K pA
Sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
Excessive noise can result in a loss of hearing.
32 | GB
2 pcs.
8500 rpm
970 x 490 x 485 mm
27 kg
254 mm
2 mm
635 x 127 mm
90°-135°
920 x 264 mm
254 mm
120 mm
2 mm
380 x 254 mm
230 V / 50 Hz
1500 W
89 dB
3 dB
102 dB
3 dB
www.scheppach.com
Keep the noise level and vibration to a minimum!
• Only use faultless devices.
• Maintain and clean the device at regular intervals.
• Adapt your working methods to the device.
• Do not overload the device.
• Have the device checked if necessary.
• Switch the device off if it is not in use.
7. Before commissioning
Before each use, always check:
• On/off switch incl. emergency stop switch (if pres-
ent) for proper function
• Interlocked guards (Fig. 1a - Pos. 3) by succes-
sive opening of each guard to switch off the ma-
chine and by checking that it is impossible to
switch on the machine with a guard open
• Brake
when starting work, switch on the machine and let
it come up to speed. Now switch the machine off
again. The engine must stop within 10 seconds.
Otherwise, there is a defect.
• Anti-kickback claws (Fig. 4 - Pos. 25)
at least once per work shift by inspection to check
that they are in good working condition, e.g. have
no damage to the contact surface from impact and
that the anti-kickback claws (25) fall back unhin-
dered by their own weight;
• Planer blade (Fig. 13 - Pos. 24)
must be checked for damage and correct fit.
The machine may only be used if all these condi-
tions are met.
Use only saw blades that are well sharpened and
maintained. Only use blades designed for the ma-
chine.
Use wooden push blocks or push sticks that are not
defective when machining short workpieces.
Connect the machine to a dust or chippings extrac-
tion system.
Check that the stop is firmly clamped in place before
you start machining.
Ensure that you can keep your balance at all times.
Stand to the side of the machine.
Keep your hands at a safe distance from the cutting
roller and from the point where the chips are ejected
when the machine is running.
Do not start planing until the cutting roller has reached
its required speed.
