5.3.3 Type key
Code Example
Type range
System type
E All pumps with E motor
EC All pumps with CUE
F Fixed-speed pumps, 1 CUE
EF All VFD non CUE
S Fixed-speed pumps
E2 2000 series
Number of main pumps
Main pump current
Start method
E Electronic
DOL Direct-on-line starter
SD Star-delta starter
SST Soft starter
Voltage supply
U11 3 x 400 V, 50 Hz, PE
U12 3 x 400 V, 60 Hz, PE
U13 3 x 400 V, 50 Hz, N, PE
U14 3 x 400 V, 60 Hz, N, PE
U15 3 x 380 V, 50 Hz, PE
U16 3 x 380 V, 50 Hz, N, PE
UX
Design
W Wall mounting
F Floor standing
O Outdoor
X Customized
Standard versions
A Standard version A
O10: Dry-running protection, digital input (or O9)
O9: Dry-running protection, inlet-pressure sensor (or O10)
O1: Redundant primary sensor (prepared fo connection only)
O2: Show repair switches in wiring diagram
B Standard version B
O10: Dry-running protection, digital input (or O9)
O9: Dry-running protection, inlet-pressure sensor (or O10)
O1: Redundant primary sensor (prepared for connection only)
O2: Show repair switches in wiring diagram
O3: Emergency operation switch (mounted in panel)
C Standard version C
O10: Dry-running protection, digital input (or O9)
O9: Dry-running protection, inlet-pressure sensor (or O10)
O1: Redundant primary sensor (prepared for connection only)
O2: Show repair switches in wiring diagram
O12: Operation light pump (lamp in front door)
O11: Fault light pump (lamp in front door)
O16: Voltmeter (in front door)
O15: Ammeter (in front door)
D Standard version D
O10: Dry-running protection, digital input
O9: Dry-running protection, inlet-pressure sensor
O1: Redundant primary sensor
O2: Show repair switches in wiring
O3: Emergency operation switch
O4: IO 351B interface
E Standard version E
O7: Dry-running protection, electrode relay
O1: Redundant primary sensor
O2: Show repair switches in wiring diagram
O3: Emergency operation switch
F Standard version F
O8: Dry-running protection, vibration limit switch
O1: Redundant primary sensor
O2: Show repair switches in wiring diagram
O3: Emergency operation switch
Option
O
See 5.3.4 Optional equipment
8
Control MPC E 6x 000A DOL U1 W A O
