8.7.66 Display language (4.5.1)
Fig. 118Display language
Description
Here you select the language for the CU 352 display.
Setting range
• English
• German
• Danish
• Spanish
• Finnish
• French
• Greek
• Italian
• Dutch
• Polish
• Portuguese
• Russian
• Swedish
• Chinese
• Korean
• Japanese
• Czech
• Turkish
• Hungarian
• Bulgarian
• Croatian
• Latvian
• Lithuanian
• Romania
• Slovak
• Slovenian
• Serbian Latin
• US English
• Indonesian
• Malay
• Estonian.
Setting via the operating panel
• Settings > Functions, CU 352 > Display language.
Factory setting
The display language is British English. It can be changed at
startup.
66
8.7.67 Units (4.5.2)
Fig. 119Units
Description
Here you can select units for the various parameters.
Select between SI and imperial units. You can also select other
units for the individual parameters.
Setting range
Basic setting
Parameter
SI Imperial
Pressure bar psi
Differential
m psi
pressure
Head m ft
Level m ft
3
Flow rate m /h gpm
3
Volume m gal
Specific
3
kWh/m Wh/gal
energy
Temperature °C °F
Differential
K K
temperature
Power kW HP
Energy kWh kWh
If units are changed from SI to imperial or vice versa,
all individually set parameters will be changed to the
basic setting in question.
Possible units
kPa, MPa, mbar, bar, m, psi
kPa, MPa, mbar, bar, m, psi
m, cm, ft, in
m, cm, ft, in
3 3 3
m /s, m /h, l/s, gpm, yd /s,
3 3
yd /min, yd /h
3 3
l, m , gal, yd
3
kWh/m , Wh/gal, Wh/kgal,
BTU/gal, HPh/gal
K, °C, °F
K
W, kW, MW, HP
kWh, MWh, BTU, HPh
