PAR. DESCRIPTION
Select the unit of measurement of probe 1.
• NTC/PTC: C (0) = °C, F (1) = °F;
dro • Pt100-Tc: C (0) = °C, F (1) = °F;
• V/I: n (0) = No unit of measure selected; t (1) = Temperature;
P (2) = Pressure; H (3) = Humidity.
CONFIGURATION (folder 'CnF')
Probe type selection.
• NTC/PTC: Ptc (0) = PTC; ntC (1) = NTC;
H00 • Pt100-Tc: Jtc (0) = TcJ; Htc (1) = TcK; Pt1 (2) = Pt100;
• V/I: 420 (0) = 4...20 mA; 020 (1) = 0...20 mA; t10 (2) = 0...10 V;
t05 (3) = 0...5 V; t01 (4) = 0...1 V.
H01 Output link: 0 = Independent; 1 = Dependent; 2 = Neutral Zone (or window).
Press the ESC, UP and DOWN keys (if configured for a second function) for the
H02 time H02 to activate the function itself.
N.B.: The AUX function has a fixed activation time of 1 second.
Lower input current/voltage limit.
H03
(only present on model V/I).
Upper current/voltage limit for input.
H04
(only present on model V/I).
H05 Window filter: -2 = Very fast; -1 = Fast; 0 = Normal; 1 = Slow; 2 = Very slow.
Key or Digital Input with AUX/light active with the device OFF (but powered).
H06
n (0) = Not active; y (1) = Active.
Stand-by operating mode.
H08 0 = Only display switches off; 1 = Display on and controllers locked;
2 = Display off and controllers locked.
Delay for output activation after Power On. If H10 = 0 the delay is NOT active; if
H10
H10 ≠ 0 the output will not be activated before this time has expired.
If one or more parameters are changed, the controller MUST be switched off and switched on again.
30
MODEL RANGE VALUE M.U. LEVEL
NTC/PTC C/F
Pt100-Tc
C/F
V/I n/t/P/H
NTC/PTC Ptc/ntC
Pt100-Tc Jtc/Htc/Pt1
420/020
V/I
t10/t05/t01
ALL 0/1/2
ALL 0...15
NTC/PTC
Pt100-Tc
V/I -1999...1999
NTC/PTC
Pt100-Tc
V/I -1999...1999 1000
ALL -2/-1/0/1/2
ALL n/y
ALL 0/1/2
ALL 0...250
C flag
C flag
Inst
n num
ntc flag
Jtc num
User/Inst
420 num
0 num Inst
5 secs Inst
User/Inst
0 num
User/Inst
num
0 num Inst
y flag Inst
2 num Inst
0 min Inst
