Input/Output Characteristics
See Connections section
Mechanical Characteristics
Casing:
Dimensions:
Terminals:
Connectors:
Humidity:
Regulations
Food Safety:
NOTE: The technical specifications given in this document regarding measurement (range, accuracy, resolution, etc.) refer
to the instrument and not to any accessories provided, such as the probes.

FURTHER INFORMATION

PC+ABS UL94 V-0 resin casing, polycarbonate window, thermoplastic resin keys
front panel 78.6x37 mm (3.09x1.46 in.), depth 59 mm (2.32 in.) (without terminals)
screw/disconnectable terminals for cables with a diameter of 2.5 mm
TTL for connection of UNICARD/Copy Card (Max length= 3 m (9.84 ft))
Operating / Storage: 10...90 % RH (non-condensing)
The device complies with standard EN13485 as follows:
• suitable for storage
• application: air
• climate range A
• measurement class 1 in the range from -25 ... 15 °C (-13 ... 59 °F) (*)
(* exclusively using Eliwell probes)
23
(13 AWG)
