PAR. DESCRIPTION
Baudrate selection.
bAU
48 (0) = 4800; 96 (1) = 9600; 192 (2) = 19200; 384 (3) = 38400.
Pty Modbus parity bit. n (0) = None; E (1) = Even; o (2) = Odd.
StP Modbus stop bit. 1b (0) = 1 bit; 2b (1) = 2 bit.
DISPLAY (folder 'diS')
LOCk. Setpoint edit lock. The parameter programming menu can still be
LOC
accessed, and the settings changed, which means also that the status of this
parameter can be changed so as to unlock the keypad. n (0)= No; y (1) = Yes.
Password 1. When enabled (PS1 ≠ 0) it is the password to the User
PS1
parameters (User).
Password 2. When enabled (PS2 ≠ 0) it is the password to the Installer
PS2
parameters (Inst).
Display values with decimal point. n (0) = No (without decimal point);
ndt
y (1) = Yes (with decimal point); int (2) = Integer (V/I models only).
Calibration 1. Positive or negative value added to the value read by Pb1,
CA1
according to the setting of parameter CAI.
Intervention of the offset on display, temperature control or both.
0 = Only the value shown is modified;
CAI
1 = Sum with only the value used by the controllers and not for the display,
which remains unchanged;
2 = Sum with the displayed value, which is also used by the regulators.
LdL Minimum value that can be displayed by the device.
HdL Maximum value that can be displayed by the device.
MODEL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
NTC/PTC
Pt100-Tc
V/I
ALL
NTC/PTC
Pt100-Tc
V/I
NTC/PTC
Pt100-Tc
V/I
29
RANGE VALUE M.U. LEVEL
48/96/
96 num
192/384
n/E/o E num
1b/2b 1b flag
n/y n flag
0...250 0 num User/Inst
0...250 15 num
n/y/int n num User/Inst
-30.0...30.0 0.0 °C/°F
-30.0...30.0 0.0 °C/°F
-30...30 0 num
0/1/2 2 num
-199.9...HdL -50.0 °C/°F
-328...HdL -199.9 °C/°F
-199...HdL -199 num
LdL...199.9 140.0 °C/°F
LdL...1350 1350 °C/°F
LdL...199 199 num
Inst
Inst
Inst
User/Inst
Inst
User/Inst
Inst
Inst
Inst
