PAR. DESCRIPTION
Switch-on delay. The indicated time must elapse between the request for
dn1
activation of the controller 1 relay and switch-on. 0 = Not active.
Delay time after switching off. The indicated time must elapse between
dO1
deactivation of the controller 1 relay and the next switch-on. 0 = Not active.
Delay between switch-ons. The indicated time must elapse between two
di1
consecutive switch-ons of regulator 1. 0 = Not active.
Switch-off delay. The indicated time must elapse between the request for
dE1
deactivation of the controller 1 relay and switch-off. 0 = Not active.
Controller 1 switch-on time in the event of inoperable probe.
On1 • if On1=1 and OF1=0, the controller remains on;
• if On1=1 and OF1>0, the controller operates in Duty Cycle mode.
Controller 1 switch-off time in the event of inoperable probe.
OF1 • if OF1=1 and On1=0, the controller remains off;
• if OF1=1 and On1>0, the controller operates in Duty Cycle mode.
REGULATOR 2 (folder 'rE2')
HC2 This sets the controller 2 operating mode. H (0) = Hot; C (1) = Cold.
OS2 Value to be added to SP2 if reduced set enabled.
Operating band 2.
db2
(See 'ON/OFF regulation diagram').
Regulator 2 activation differential. The utility stops on reaching the SP2 value
dF2 (as indicated by control probe) and restarts at a value equal to T=SP2+dF2
relative to HC2.
HS2 Maximum value assignable to setpoint SP2.
MODEL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
NTC/PTC
Pt100-Tc
V/I
NTC/PTC
Pt100-Tc
V/I
NTC/PTC
Pt100-Tc
V/I
NTC/PTC
Pt100-Tc
V/I
26
RANGE VALUE M.U. LEVEL
0...250 0 secs
0...250 0 min
0...250 0 min
0...250 0 secs
0...250 0 min
0...250 1 min
H/C H flag
-30.0...30.0 0.0 °C/°F
-30.0...30.0 0.0 °C/°F
-30...30 0 num
0.0...30.0 1.0 °C/°F
0.0...30.0 1.0 °C/°F
0...30 1 num
0.0...30.0 1.0 °C/°F
0.0...30.0 1.0 °C/°F
0...30 1 num
140.0 °C/°F
LS2...HdL 1350 °C/°F
199 num
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
User/Inst
User/Inst
