Classification:
Mounting:
Type of action:
Pollution class:
Insulation material class:
Overvoltage category:
Rated impulse voltage:
Temperature:
Power supply:
Consumption:
Fire resistance category:
Software class:
External fuse (mandatory):
Allowed Conductors:
Protection against electric shock:
NOTE: - check the power supply specified on the instrument label; contact our Sales Office for power and relay ratings.
- For the 12 Vac/dc and 12-24 Vac/12-36 Vdc version, use a dedicated power supply source.
TECHNICAL DATA (EN 60730-2-9 and UL 873)
operation (not safety) device for incorporation
panel mounting with 71x29 mm (2.80x1.14 in.) drilling template
1.B
2
IIIa
II
2500 V
UL models: 0...55 °C (32...131 °F) - Storage: -30...85 °C (-22...185 °F)
other: -5...55 °C (23...131 °F) - Storage: -30...85 °C (-22...185 °F)
• 12 Vac/dc (±10 %) SELV (Safety Extra Low Voltage)
• 24 Vac (±10 %)
• 12-24 Vac/12-36 Vdc (±10 %) SELV (Safety Extra Low Voltage)
• 115 Vac (±10 %) 50/60 Hz
• 230 Vac (±10 %) 50/60 Hz
• 1.5 VA max (model 12 Vac/dc)
• 4 VA max (models: 24 Vac, 12-24 Vac/12-36 Vdc, 115 Vac and 230 Vac)
D
A
Approved, slow-blow 500 mA fuse (T500mAH250V)
(Models: 12 Vac/dc and 12-24 Vac/12-36 Vdc)
Use Copper Conductors Only
Class II control intended for use in Class I Equipment
22
