CONNECTIONS
V/I (12 Vac/dc, 12-24 Vac/12-36 Vdc)
OUT1 OUT2
1 2 3 4 5 7
Supply
V/I (24 Vac, 115 Vac, 230 Vac)
OUT1 OUT2
1 2 3 4 5 6 7
Supply
1-2-3 Regulator relay OUT1
4-5 Regulator relay OUT2
*6-7
Power supply 24 Vac, 115 Vac and 230 Vac
FUSE
Approved external fuse, slow-blow 500 mA fuse (T500mAH250V) (12 Vac/dc and 12-24 Vac/12-36 Vdc models)
A TTL input for Copy Card and TelevisSystem connection
V/I MODEL
Display range:
Digital input
Analogue input
8 9 10 11 12
− + +
V
Serial
I
+12 V
Digital
outputs
9 10 11 12
Buzzer output
− + +
Measurement range -1999 ... 1999
V
Accuracy
I
+12 V Resolution
INPUT/OUTPUT CHARACTERISTICS
-199...199 (ndt = n)
-199.9...199.9 (ndt = y)
-1999...1999 (ndt = int) on display with 3½ digits + sign
1 digital voltage free input
1 V/I (0-1 V, 0-5 V, 0-10 V, 0...20 mA, 4...20 mA)
(H00 parameter)
Maximum load: I = 100 Ω - V = 20 kΩ
TTL for connection to Copy Card or Televis/Modbus
remote control systems
EN60730: 1 SPDT NO 8(4) A NC 6(3) A 250 Vac max
OUT1: UL 873: 1 SPDT NO/NC 8 A, 240 Vac G.P.;
EN60730: 1 SPST NO 8(4) A 250 Vac max
OUT2: UL 873:
only on models where this is provided
better than 0.5 % of end of scale +1 digit
1 or 0.1 digit according to settings
TERMINALS
*7-8 Power supply 12 Vac/dc and 12-24 Vac/12-36 Vdc
*9-10-12 Voltage input (9=GND; 10="+"; 12=12 V)
*9-11-12 Current input (9=GND; 11="+"; 12=12 V)
* depends on model
12
4.9 FLA / 29.4 LRA, 240 Vac
1 SPST NO 8 A, 240 Vac G.P.;
4.9 FLA / 29.4 LRA, 240 Vac
