PAR. DESCRIPTION
Digital Input Configuration. 0 = Disabled; 1 = SOFT START; 2 = Offset setpoint;
H11 3 = Outputs stopped; 4 = Periodic cycle; 5 = AUX; 6 = Stand-by;
7 = Not used; 8 = External alarm; 9 = External alarm to lock regulators.
Polarity and priority of Digital Inputs (D.I.).
H13 no (0) = Normally open; nc (1) = Normally closed;
noP (2) = Normally open with priority; ncP (3) = Normally closed with priority.
H14 Digital input activation delay.
Configuration of Digital Output1 (OUT1). 0 = Disabled; 1 = On-off (controller 1)
H21
2 = On-off (controller 2); 3 = Alarm; 4 = Cyclic; 5 = AUX/Light; 6 = Stand-by.
H22 Configuration of Digital Output2 (OUT2). Same as H21.
Configuration of UP key. 0 = Disabled; 1 = SOFT START; 2 = Offset setpoint;
H31
3 = Outputs stopped; 4 = Periodic cycle; 5 = AUX output; 6 = Stand-by; 7 = Not used.
H32 Configuration of DOWN key. Same as H31.
H33 Configuration of ESC key. Same as H31.
rEL firmware version. Device software release: read-only parameter.
tAb Parameters table. Reserved: read-only parameter.
COPY CARD (folder 'FPr')
UL Upload. Transfer of programming parameters from instrument to Copy Card.
dL
Download. Transfer of programming parameters from Copy Card to instrument.
Format. Cancels all data entered in the Copy Card.
Fr Note: If parameter Fr (Copy Card formatting) is used, the data entered in the
card will be permanently lost. This operation cannot be reversed.
MODEL
NTC/PTC
Pt100-Tc
V/I
NTC/PTC no/nc/noP/ncP
Pt100-Tc no/nc/noP/ncP
V/I
NTC/PTC
Pt100-Tc
V/I
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
31
RANGE VALUE M.U. LEVEL
0..9 0 num
0...9 0 num
no num
no num
0...250 0 min
0...250 0 min
0...6 1 num
0...6 2 num
0...7 0 num
0...7 0 num
0...7 6 num
/ / /
/ / /
/ / /
/ / /
/ / /
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
User/Inst
User
Inst
Inst
Inst
