PAR. DESCRIPTION
Establishes which outputs the function must be enabled on:
Sen
0 = Disabled; 1 = OUT 1; 2 = OUT 2; 3 = OUT 1 & 2.
Function reactivation threshold. Establishes the threshold beyond which the
Sdi
SOFT START function is automatically reactivated.
CYCLIC CONTROLLER (folder 'cLc')
Con Output ON time.
CoF Output OFF time.
ALARMs (folder 'AL')
Parameters HA1/HA2 and LA1/LA2, intended as the absolute value or
Att differential in relation to the setpoint SP1/SP2.
AbS (0) = Absolute value; rEL (1) = Relative value.
AFd Alarm differential.
PAO Alarm override time after device is switched on following a power failure.
Alarm exclusion time until the Setpoint is reached.
SAO 0 = Disabled. If SAO >0, an alarm will be generated if the Setpoint is not
reached after the time SAO (in hours).
tAO Delay preceding indication of temperature alarm.
Alarm output polarity. nC (0) = Alarm active and output disabled;
AOP
nO (1) = Alarm active and output enabled.
tP Enable all keys to acknowledge an alarm. n (0) = No; y (1) = Yes.
COMMUNICATION (folder 'Add')
PtS Selection of communication protocol. t (0) = Televis; d (1) = Modbus.
dEA Index of the device within the family (valid values from 0 to 14).
FAA Device family (valid values from 0 to 14).
Adr Modbus protocol controller address.
MODEL
ALL
NTC/PTC
Pt100-Tc
V/I
ALL
ALL
ALL
NTC/PTC
Pt100-Tc
V/I
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
28
RANGE VALUE M.U. LEVEL
0/1/2/3 0 num
1.0...50.0 2,0 °C/°F
1.0...50.0 2.0 °C/°F
1...50 2 num
0...250 0 min
0...250 0 min
AbS/rEL AbS flag
1.0...50.0 2.0 °C/°F
1.0...50.0 2.0 °C/°F
1...50 2 num
0...10 0 hours
0...10 0 hours
0...250 0 min
nC/nO nC flag
n/y y flag
t/d t flag
0...14 0 num
0...14 0 num
1...255 1 num
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
Inst
