Minimum alarm
Maximum alarm
Returning from minimum
Returning from maximum Temp. ≤ SP1/2 + HA1/2 - AFd (HA1/2>0)
MAX/MIN TEMPERATURE ALARMS
Temperature as a value
relative to Setpoint (Att=1)
AFd
SP1/SP2
SP1/SP2 + LA1/2
SP1/SP2 + LA1/2 + AFd
Temp. ≤ SP1/2 + LA1/2 *
Temp. ≥ SP1/2 + HA1/2 **
Temp. ≥ SP1/2 + LA1/2 + AFd or
≥ SP1/2 - ILA1/2I + AFd (LA1/2<0)
* if LA1/2 is negative, SP1/2+LA1/2 < SP1/2
** if HA1/2 is negative, SP1/2+HA1/2 < SP1/2
AFd
SP1/SP2 + HA1/2
SP1/SP2 + HA1/2 – AFd
19
Temperature as an
Absolute value (Att=0)
AFd
LA1/2
LA1/2 + AFd LA1/2 - AFd
Temp. ≤ LA1/2 (LA1/2 with sign)
Temp. ≥ HA1/2 (HA1/2 with sign)
Temp. ≥ LA1/2 + AFd
Temp. ≤ HA1/2 - AFd
AFd
HA1/2
