The table below displays the type and the size of cables for screw terminals with pitch 5,00 mm (0.197 in.) or 5,08 mm (0.2 in.).
7
mm
0.28
in.
mm
2 0.2...2.5
AWG 24...13
Ø 3.5 mm (0.14 in.)
This device has been designed to operate outside of any hazardous location.
Only install this device in zones known to be free of hazardous atmosphere.
POTENTIAL FOR EXPLOSION
Only install this device in zones known to be free of hazardous atmosphere.
Failure to follow these instructions will result in death or serious injury.
Electrical equipment should be installed, operated, serviced, and maintained only by qualified personnel.
No responsibility is assumed by Eliwell for any consequences arising out of the use of this material.
0.2...2.5 0.25...2.5 0.25...2.5
24...13 22...13 22...13
N•m 0.5...0.6
C
lb-in 4.42...5.31
2 x 0.2...1 2 x 0.2...1.5 2 x 0.25...1
2 x 24...18 2 x 24...16 2 x 22...18
DANGER
7
2 x 0.5...1.5
2 x 20...16
