6.2 Setup menu

All settings are preset except for the start level. The start level
depends on the inlet height and must be set during the start-up
phase. See section 8.4 Setting of LC
adjustments are required, settings can be made via the setup
menu. To open the setup menu, mark the symbol
button and press the button
means of the buttons and
pressing the button . Enter values or select settings from a list
by means of the buttons and
the button . See also fig. 15.
Setup menu
Fig. 15 Menu structure for setup menu
*) These submenus are only needed when changing sensor
type. The sensors for Multilift MOG and MDG are already
calibrated. For more information, see service instructions.
16
221. However, in case
using the
. Navigate through the menu by
. Select the desired menu item by
. Save the settings by pressing
L_01 Start Level [mm]
I_02 Rated current [A]
T_01 Stop delay [sec.]
T_02 Start delay [sec.]
T_03 Alarm delay [sec.]
S_01 Sensor selection
C_01 Calibration
M_01 Maintenance interval [month]
A_01 Reset alarm
G_01 Reset to factory settings
EXIT Back to main menu
The following settings can be made:
• start level
• rated current
• stop delay
• start delay
• alarm delay
• sensor selection
• sensor calibration
• sensor offset
• time for maintenance
• alarm reset (manually or automatically)
• reset to factory settings.
180
250
315
3.8
2
0
5
S00, S01
490
C_02 Offset
0, 3, 6, 12
Manual
Automatic
EXIT
*)
