TECHNICAL DATA, SERIES 90C-2
Basic unit: __________________________ Actuator controller with plastic housing,
_________________________________________ prewired for supply and sensors
Dimensions (HxWxT): ______________________________approx. 95x135x85 mm
Display: ________________________________ fully graphical display 128x64 dots
Light emitting diode: ______________________________ polychrome / multicolour
Operation: ___________________________________________________ input keys
Power supply: ________________________________ 230 ±10% V AC, 50/60 Hz
Power consumption: ___________________________________________ ca 5.0 VA
Total switching capacity of the relay outputs 1-3:
_______________________________2 (0,8) A 250 VAC (Circulation pump 185W)
Enclosure rating:_______________________________IP 54 as per DIN 40050 CE
Protection class: _____________________________________________________ II
Ambient temperature: ____________________________________ 0° to 40°C max.
Ambient atmospheric humidity: ________________________max. 85% RH at 25°C
Actuator: _______________________________________ Running time 120 s/90°
Torque: _______________________________________________________ 15 Nm
Mixer valve operation range: ____________________________ 90 / 180 or 270º
Sensors: _______________________________ Temperature sensor type PT1000
Sensor cable: _______________________________ 4x0.38mm
Temperature range: Flow pipe sensor CRS211 ________________ 0 to +105°C
Outdoor sensor CRS214 ________________ –50 to +70°C
Universal sensor CRS213 ________________ 0 to +105°C
Room sensor CRS231 __________________ +10 to +30°C
Weight: ________________________________________________________ 0.9 kg
Temperature resistance table for Pt1000 sensors:
T./°C 0 10 20 30 40
R./ Ω 1000 1039 1077 1116 1155 1194 1232 1270 1308 1347 1385
2 , max. length 30m
50 60 70 80 90 100

SAFETY INSTRUCTIONS

EC DECLARATION OF CONFORMITY
By affixing the CE mark to the unit the manufacturer declares that the series 90C-2
conforms to the following relevant safety regulations:
EC low voltage directive LVD 2006/95/EC
EC electromagnetic compatibility directive EMC 2004/108/EC
Conformity has been verified and the corresponding documentation and the EC declaration
of conformity are kept on file by the manufacturer.
GENERAL INSTRUCTIONS
These installation and operating instructions contain basic instructions and important
information regarding safety, installation, commissioning, maintenance and the optimal use
of the unit. Therefore these instructions must be read completely and understood by the
installation technician/specialist and by the system user before installation, commissioning
and operation of the unit.
The valid accident prevention regulations, the regulations of the local power utility, the
applicable ISO-EN standards and the installation and operating instruction of the additional
system components must also be observed. The controller does not under any circumstan-
ces replace any safety devices to be provided by the customer!
Installation, electrical connection, commissioning and maintenance of the unit may only be
carried out by specialists who possess the appropriate training.
For the user: Make sure that the specialist gives you detailed information on the function
and operation of the controller. Always keep these instructions in the vicinity of the controller.
EXPLANATION OF SYMBOLS
Failure to observe these instructions can result in danger to life from
electric voltage.
DANGER
Failure to observe these instructions can result in destruction of the unit
or the system, or damage to the environment.
CAUTION
Information which is especially importation for the function and optimal use
of the unit and the system.
ATTENTION
It is essential that you read this!
